TRENDnet 300Mbps Wireless N-Draft PCI Adapter
| |
Item Code: |
TEW-623PI |
| |
Availability: |
In Stock. |
| |
Price: |
$
49.95 |
|
 |
$
49.95 |
|
|
 |
The Wireless N PCI Adapter allows you to connect wirelessly with
supercharged speed, range and reliability. This 802.11n device
seamlessly connects to your wireless network without performance
degradation.
Wireless speeds increase up to 300Mbps* when connecting to TRENDnet
Wireless N access points or wireless routers. The latest antenna
technology increases wireless data coverage throughout homes and
businesses. It also supports universal wireless connectivity with
802.11b or 802.11g networks. Advanced wireless encryption provides
secured transmissions. Increased speed and throughput makes it the
perfect solution to fulfill your multimedia needs.
**Maximum wireless signal rates
are referenced from IEEE 802.11 theoretical specifications. Actual data
throughput and coverage will vary depending on interference, network
traffic, building materials and other conditions.
| Features |
- Wi-Fi compliant with the wireless IEEE 802.11n standard
- Extreme wireless performance: Up to 12x the speed of wireless g* (IEEE 802.11g)
- Up to 4x the coverage of wireless g*
- Advanced wireless encryption: WEP, WPA, WPA2, WPA-PSK and WPA2-PSK
- 3 detachable high gain antennas maximize wireless n performance with Multiple Input Multiple Output (MIMO) technology
- Intuitive user setup and diagnostics utilities
- Backwards compatible with wireless g and wireless b standards (IEEE 802.11b/g)
- Supports Ad-hoc (Client-Client) and Infrastructure (AP-Client) mode
- Maximum reliability, throughput and connectivity with automatic data rate switching and dynamic data rate scaling
- Seamless roaming between wireless b, wireless g and wireless n networks
- Compatible with Windows 2000/XP/Vista operating systems
- 3 year warranty
|
|
| Specifications |
| Hardware |
Interface |
32-Bit PCI Rev. 2.1/2.2/2.3 |
Standards |
IEEE 802.11b, IEEE 802.11g and IEEE 802.11n (draft 2.0) |
LED Indicator |
PWR (power), LNK (link activity) |
Power Consumption |
650mA (max) |
Supported OS |
Windows 2000/XP/Vista (32/64-bit) |
Weight |
85g (3 oz) |
Temperature |
Operating: 0° ~ 40° C (32° ~ 104° F)
Storage: -25° ~ 70° C (-13° ~ 158° F) |
Humidity |
10% ~ 90%max (non-condensing) |
Certification |
FCC, CE |
|
| Wireless |
Module Technique |
- 802.11b: CCK (11 and 5.5Mbps), DQPSK (2Mbps), DBPSK (1Mbps)
- 802.11g: OFDM with BPSK, QPSK and 16/64-QAM sub-carrier modulations
- 801.11n: OFDM, 64-QAM, coding rate 5/6
|
Antenna |
3 x 2dBi detachable antennas (Reverse SMA connector) |
Frequency |
2.412 ~ 2.484 GHz |
Media Access Protocol |
CSMA/CA |
Data Rate (auto fallback) |
- 802.11b: 11Mbps, 5.5Mbps, 2Mbps, and 1Mbps
- 802.11g: 54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 9Mbps and 6Mbps
- 802.11n (draft) : up to 300Mbps
|
Output Power |
- 802.11b: 18dBm (typical)
- 802.11g: 15dBm (typical)
- 802.11n (draft 2.0) : 7dBm (typical) with 130Mbps/HT20 & 270Mbps/HT40
|
Receiving Sensitivity |
- 802.11b: -86dBm (typical) @ 11mpbs
- 802.11g: -74dBm (typical) @ 54Mbps
- 802.11n (draft 2.0) : -70dBm @ 130Mbps/HT20 & -65dBm @ 270Mbps/HT40
|
Encryption |
64/128-bit WEP (Hex & ASCII), WPA/WPA2(TKIP/AES), WPA-PSK/WPA2-PSK, 802.1x |
Channels |
1~11 (US), 1~13 (EU) |
|
|
